THE PEAK OF
Comfort & Design
MARK LEVINSON QLI REFERENCE SOUND SYSTEM
A 23-speaker system that includes speakers in the ceiling ensures unprecedented sonic quality in an accurate and enveloping soundstage.
LED TURN SIGNALS
Lexus’ all-LED turn signal is a powerful combination of 16 bulbs that emit a brilliant glow, yet artfully conceal their presence when turned off.
TAILORED FOR COMFORT
Seats feature a shiatsu massage function with ventilation to deliver a soothing and refreshing environment.
ADJUSTABLE POWER SUNSHADE
All rear seat windows have power sunshades for protection against the glaring sun, achieving optimal lighting for utmost comfort and privacy.
Optitron Technology, pioneered by Lexus, improves meter clarity with crystal-clear illumination on the dials and fully illuminated needles.
Rear seat passengers enjoy the comfort of an ottoman seat with adjustable seat cushions that support calves.
AUTO LIFT-UP FUNCTION
A Lexus-first air suspension system automatically raises the vehicle for passengers to enter and exit with comfort and ease.
INFRARED RAYS MATRIX SENSOR
Extensive infrared sensors detect the body temperature of all occupants to enable precise climate control for each passenger.
Hand-crafted diamond shaped pleats adorn the vehicle’s cabin for a delicate touch of exquisite originality.
HANDS-FREE POWER TRUNK LID
A sensor underneath the rear bumper allows you to effortlessly open and close the trunk lid with a simple sweep of your feet.
COMPACT WITH GREATER POWER
Under the hood of the LS 500 is a 3.5-litre twin turbo V6 engine, the first-ever in the LS series. The compact engine achieves high driving performance as well as reduced fuel consumption.
The artificial intelligence transmission logic (AI-Shift Control) anticipates the driver’s input by monitoring acceleration, braking and lateral-g forces to execute perfectly timed, ultra-quick shifts.
DRIVE MODE SELECT
Select performance to match your driving style with six drive modes: NORMAL, ECO, COMFORT, SPORT S, SPORT S+, and Custom.
ADAPTIVE VARIABLE SUSPENSION
AVS continually adjusts shock-absorber damping rates while driving, delivering the type of smooth ride expected of a Lexus.
10-SPEED AUTOMATIC TRANSMISSION
Seamless acceleration and rhythmical gear shifts are achieved with a redesigned Direct Shift 10-speed automatic transmission.
12 SRS AIRBAGS
Collision impact is greatly reduced with 12 sensor-controlled SRS airbags lining the cabin, providing enhanced protection for all occupants.
The PCS is a collection of intelligent warning sensors placed around the car that alert you and help to avoid potential accidents.
BLIND SPOT MONITOR
Know when vehicles are approaching from behind, even at higher speeds, with the next-generation Blind Spot Monitor.
LANE DEPARTURE ALERT
When you drift into another lane without a turn signal, the LDA system alerts you and applies steering force to assist in avoiding lane departure.
A combination of features accurately guides your parking attempts and provides additional driving and braking force to prevent any collisions.
DYNAMIC RADAR CRUISE CONTROL
The Dynamic Radar Cruise Control helps your Lexus maintain a safe distance from the vehicle in front of you.
AUTOMATIC HIGH BEAM SYSTEM
The high beam lamps are turned on only when other vehicles are not detected to enhance nighttime visibility without blinding other drivers.
View the status of your navigation system, or check on fuel economy and the air-conditioning all on one fully customizable, 12.3-inch display.
Engine Type V6, Twin Turbocharged, 24-valve DOHC,VVT-iE (intake), VVT-i (exhaust) Drive Rear-wheel Drive Transmission Type 10-speed Automatic Transmission Bore x Stroke 85.5 x 100.0 mm Displacement 3,445 cc Compression Ratio 10.476 Max. Output 310kW (415 BHP) / 6,000 rpm Max. Torque 600 Nm / 1,600 - 4,800 rpm Max. Speed 250 km / h Acceleration (0-100 km / h) 5.0 sec Fuel Consumption 9.5 L / 100 km [10.5 km / L] CO₂ Emissions 217 g/km
Brake Ventilated Disc Brake Suspension (Front) High Mount Multi-link Suspension (Rear) Multi-link Steering System Electronic Power Steering
Overall Length 5,235 mm Width 1,900 mm Height 1,450 mm Wheelbase 3,125 mm Tread (Front) 1,630 mm Tread (Rear) 1,635 mm Min Turning Radius 5.7 m Coefficient of Drag 0.29 Kerb Weight 2,220 - 2,250 kg Gross Vehicle Weight 2,670 kg Boot Capacity 440 L Fuel Tank Capacity 82 L
Electrically Adjustable Steering Wheel with Paddle Shifters
Auto Retractable Wing Mirrors with memory
Electrochromic (EC) Inside Rear View Mirror
Air Ventilated Front Seats (Cooler + Heater)
Air Ventilated Rear Seats (Cooler + Heater)
Original Factory-fitted Genuine Semi-aniline Leather Seats
28-way Power Adjustable Front Seats with Shoulder, Side, Pelvic, Calf, Lumbar Support, Cushion Length Adjuster and Butterfly Headrest
LUXURY EDITION ADD-ON:Butterfly Power-retractable Front Headrests
18-way Power Adjustable Rear Seats with Shoulder, Pelvic, Lumbar Support,Cushion Length Adjuster and Butterfly Headrest
LUXURY EDITION OPTION:22-way Power Adjustable Front Seats with Shoulder, Pelvic, Lumbar Support, Cushion Length Adjuster and Butterfly Headrest with Rear Ottoman
Left-rear Power Reclining up to 48° with Sliding Ottoman
Memory Seats: FR + RR
Four-zone Independent Climate Control System with Nanoe System
Rear Centre Armrest with Integrated Touch Control Panel
Power Rear Sunshade with Power Side Door & Quarter Sunshades
Shiatsu Massage (Front Seats)
LUXURY EDITION ADD-ON:Shiatsu Massage (Rear Seats)
Rear Entertainment with 11.6" LCD Screen
Smart Keyless Go
LED Daytime Running Lamps
Bi-LED Triple 'L' Headlamps with LED Sequential Turn Indicators
LED Cornering Lamps with Multi-weather Lights
Auto Rain Sensor
24" Coloured Head-up Display Projection
Air Suspension with Access Mode + Adaptive Variable Suspension (AVS)
Drive Mode Select (Eco/Normal/Custom/Sport/Sport+)
Lexus Integrated Navigation System with 12.3" Display Screen
Lexus Remote Touch Interface
Hands-free Power Trunk Lid
USB / iPod Playback Function / AUX
AM/FM Tuner / DVD Player
Mark Levinson 3D Audio Surround Sound System with 23 Speakers
12 SRS Airbags
Blind Spot Monitor (BMS) + Rear Cross Traffic Alert (RCTA)
Electric Park Brake (EPB) with Brake Hold Function
Vehicle Dynamics Integrated Management (EPS + VSC + ABS + TCS)
Panoramic View Monitor
Lexus Safety System+ (DRCC, PCS, LDA, AHS)
Auto-location Tyre Pressure Warning System
RIMS & TYRES
Bridgestone 245/45R20 Noise-reducing Run-flat Tyres with Physical Vapour Deposition
